Ubiquiti Dream Machine Pro Max, 10 Gbps, Multi-WAN, UDM-Pro-Max
Ubiquiti Dream Machine Pro Max, 10 Gbps, Multi-WAN, UDM-Pro-Max
The Ubiquiti UDM-PRO-MAX is a professional-grade Dream Machine Pro Max designed for rack-mount installation. It features 10 Gbps multi-WAN load balancing and 2 NVR drive bays for enhanced storage capacity. This cloud gateway ensures comprehensive network management and is backed by a 2-year Warranty.
Product Code: UDM-PRO-MAX
Availability:
In Stock with Supplier (Estimated Dispatch 1-2 Days Once Order Placed)
Short Description: The UniFi Dream Machine Pro Max (UDM-Pro-Max) is a high-performance network gateway with advanced security and management features, ideal for enterprise environments. It combines powerful hardware and comprehensive networking capabilities.
Common Specs:
- Dimensions: 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2")
- Weight: 4.7 kg (10.4 lb)
- Enclosure Material: Aluminium CNC, SGCC steel
- Processor: Quad-core ARM® Cortex®-A57 at 2.0 GHz
- System Memory: 8 GB DDR4
- On-board Storage: 32 GB eMMC, Integrated 128 GB SSD
- Management Interface: Ethernet, Bluetooth
- Networking Interface: LAN: (8) GbE RJ45 ports, (1) 10G SFP+ port; WAN: (1) 2.5 GbE RJ45 port, (1) 10G SFP+ port
- Power Method: Universal AC input, 100—240V AC, 2A Max., 50/60 Hz; USP-RPS DC input, 11.5V DC, 8.7A
- Power Supply: AC/DC, internal, 100W
- Max. Power Consumption: 100W
- ESD/EMP Protection: Air: ± 15kV, contact: ± 8kV
- LCM Display: 1.3" touchscreen
- Button: Factory reset
- Ambient Operating Temperature: -10 to 40° C (14 to 104° F)
- Ambient Operating Humidity: 5 to 95% noncondensing
- Certifications: CE, FCC, IC
- Gateway Features: Redundant WAN, WiFi QoS, IDS/IPS, SD-WAN, VPN, Firewall, VLAN, Advanced QoS
