Ubiquiti G3 Reader Pro, White, NFC, IP55, 2Yr Warr

Ubiquiti Ubiquiti G3 Reader Pro, White, NFC, IP55, 2Yr Warr

Ubiquiti G3 Reader Pro, White, NFC, IP55, 2Yr Warr

Ubiquiti G3 Reader Pro, White, Third-generation, Indoor/Outdoor NFC Reader & Intercom With Apple Touch Pass Support, Outdoor IP55, 2Yrs Warr

Product Code: UA-G3-PRO-W

Availability: In Stock with Supplier (Estimated Dispatch 1-2 Days Once Order Placed)

Warranty: 1 year

$750.44 Incl. GST

Overview of the UniFi G3 Reader Pro - UA-G3-Pro-W

The Ubiquiti UniFi Access G3 Reader Pro (UA-G3-Pro-W) is a third-generation, indoor/outdoor NFC reader and intercom system designed to enhance secure access control. Key features include:

  • Multiple Unlock Methods: Supports NFC cards, PIN codes, the UniFi Identity mobile app, face unlock, and Apple Touch Pass for versatile access options.
  • Integrated Intercom Functionality: Features a built-in camera and microphone, enabling two-way audio communication and video streaming for visitor verification.
  • ADA-Compliant Video Functionality: Designed to provide video capabilities at ADA-compliant mounting heights, ensuring accessibility for all users.
  • Weather-Resistant Design: IP55-rated enclosure ensures reliable performance in various environmental conditions, with an operating temperature range of -10 to 45° C.
  • Power over Ethernet (PoE) Connectivity: Simplifies installation by delivering both power and data through a single cable connection to the UniFi Access Hub.
  • Comprehensive NFC Compatibility: Supports multiple NFC standards, including ISO/IEC 14443A/B, 15693, 18092 (Ecma 340), MIFARE Classic, MIFARE DESFire, Sony FeliCa (ID only), and NFC Forum tags T1T to T5T.
  • Enhanced Security Features: Equipped with a proximity sensor, ESD/EMP protection (Air: ±15kV, Contact: ±8kV), and compliance with UL 294 and CAN/ULC-60839-11-1 standards for robust security.
  • User-Friendly Management: Managed through the UniFi Access application (version 3.0.15 and later), providing an intuitive interface for configuration and monitoring.

Specifications for the UniFi G3 Reader Pro - UA-G3-Pro-W

Mechanical

  • Dimensions: 160 x 40.4 x 40.55 mm (6.3 x 1.59 x 1.6")
  • Weight: 136 g (4.8 oz)
  • Enclosure Material: Polycarbonate, glass
  • Mount Material: Aluminum alloy
  • Mounting Options:
    • Wall mount (Included)
    • Gangbox mount (Included)
    • Angle mount (Optional)
    • Junction box (Optional)
  • Weatherproofing: IP55

Hardware:

  • Networking Interface: (1) GbE RJ45 port
  • Connectivity:
    • BLE 4.2
    • NFC
  • Power Method: PoE, UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU
  • Power Specifications:
    • Supported Voltage Range: 48V DC
    • Max. Power Consumption: 6W
  • ESD/EMP Protection: Air: ±15kV, Contact: ±8kV
  • Sensor: Proximity sensor
  • Camera View Angle:
    • H: 96.67°
    • V: 123.15°
    • D: 153.11°
  • Microphone: Yes
  • Speaker: (1) 4 ohm, 1.5W
  • LEDs: R/G/B/W/Amber
  • Button: (1) Factory-reset
  • NFC Specifications:
    • Frequency: 13.56 MHz
    • Read Range: < 30 mm
    • Supported Technologies:
      • ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340)
      • MIFARE Classic / MIFARE DESFIRE
      • Sony FeliCa™ (ID only)
      • NFC Forum tags T1T, T2T, T3T, T4T, and T5T
      • ECP 2.0
  • Operating Environment: Outdoor use
  • Ambient Operating Temperature:
    • Device: -30 to 45° C (-22 to 113° F)
    • Display: -10 to 45° C (14 to 113° F)
    • *The display will turn off when the ambient temperature is outside the operational range, but other functions remain functional.
  • Ambient Operating Humidity: 5 to 90% noncondensing
  • Software Information:
  • UL 294 Level:
    • Destructive Attack: Level I
    • Line Security: Level I
    • Endurance: Level I
    • Standby Power: Level I
  • UL 294 Statement:
    • Compliance with IEEE 802.3 specifications was not verified as part of UL 294.
    • The equipment complies with the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.
  • PoE Cabling Requirements:Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site.
    The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm 2 ) for patch cords; 24 AWG (0.21 mm 2 ) for horizontal or riser cable.
  • CAN/ULC-60839-11-1 Grade: Grade I
  • Certifications: CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
  • Document Number and Revision: UA-G3-Pro-W/UA-G3-Pro-B, V01

Software:

  • Management Application: UniFi Access (Version 3.0.15 and later)
